GW2110 - On Device AI

GW2110 - On Device AI
Company 관악아날로그(주)
Country of sale World Wide
Booth No K-13
Inquiry Email hyewon.choi@gwanakanalog.com

The GW2110 is a state-of-the-art Edge AI chip designed to facilitate the development of advanced signal processing-related On-Device AI systems. This chip is a high-performance Synthetic Signal Processing SoC (System-on-Chip) specifically designed to enable real-time processing and data analysis.

Equipped with an on-chip Inference Accelerator (IX) based on cutting-edge CNN architecture and hardware activation functions optimized for efficient speech processing, this device can provide real-time Text-to-Speech (TTS) and Keyword Spotting (KWS) capabilities without relying on a cloud server.

Featuring multiple interfaces, including analog voltage input channels, the GW2110 seamlessly integrates with a variety of sensors. From gas sensors for detecting CO and CH4 to pressure, temperature, and humidity sensors, it empowers intelligent and user-friendly environmental monitoring. Utilizing its internal Edge AI engine and speech processing, the GW2110 offers comprehensive environmental insights and data analysis, including sensor fusion capabilities.


〈Features〉 - Real-time TTS and KWS processing without a cloud server - Multilingual TTS and KWS support - Embedded ARM® Cortex®-M4F (180MHz) - On-chip inference accelerator (IX) ▶Utilizes CNN architecture with hardware activation functions (tanh and ReLU) ▶128 MACs/cycle @FP16 (46.08GFLOPS @FP16) - DRAM-Free Architecture - Internal memory ▶128KB Program Memory ▶ 256KB Data Memory ▶1MB Shared Memory with IX - Versatile interfaces ▶UART/I2C/SPI ▶Audio output: DDAC ▶Digital mic input: PDM ▶4-channel 12-bit SAR ADC ▶USB2.0 Full Speed - Dual QSPI interfaces for external SPI NAND and SPI NOR Flash memory - Lower Power Consumption - Power management with sleep, stop, and standby modes ▶Wake-up options: RTC, GPIO, PDM - Integrated power management components: LDO, POR, BOD
〈Physical Characteristics〉 - Operating voltages ▶External supply voltage: 3.3V ▶I/O supply voltage: 3.3V ▶Analog core voltage: 1.2V ▶Digital core voltage: 1.2V - Operating temperature: -40°C ~ 85°C - Available in 8x8 0.4mm pitch 68-QFN package
〈Typical Applications〉 - Smart home automation - Voice-controlled IoT devices - Healthcare, medical, and industrial devices - Environmental monitoring - Retail, hospitality, and education - Automotive and accessibility solutions - Robotics and automation
